新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-555-1260	6.25	12	960	0.12	685	0.9	0.94	15.00	4	6.5
	10	12	600	0.12	428	0.9	1.50	15.00	4.8	6.5
	18.8	12	319	0.12	228	0.9	2.82	15.00	6	6.5
	30	12	200	0.12	142	0.9	4.50	15.00	18	6.5
	56	12	107	0.13	76	0.9	8.40	15.00	32	6.5
	90	12	66	0.13	50	0.9	13.50	15.00	52	6.5
	131	12	45	0.13	32	0.9	19.65	15.00	76	6.5
	169	12	35	0.13	25	0.9	25.35	15.00	87.5	6.5
	270	12	22	0.13	16	0.9	40.50	15.00	141	6.5
	506	12	11	0.13	9	0.9	60.00	15.00	180	6.5
	810	12	7	0.13	6	0.9	60.00	15.00	180	6.5
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-555-2460	6.25	24	960	0.1	685	0.9	0.94	15.00	4	6.5
	10	24	600	0.1	428	0.9	1.50	15.00	4.8	6.5
	18.8	24	319	0.1	228	0.9	2.82	15.00	6	6.5
	30	24	200	0.1	142	0.9	4.50	15.00	18	6.5
	56	24	107	0.1	76	0.9	8.40	15.00	32	6.5
	90	24	66	0.1	50	0.9	13.50	15.00	52	6.5
	131	24	45	0.1	32	0.9	19.65	15.00	76	6.5
	169	24	35	0.1	25	0.9	25.35	15.00	87.5	6.5
	270	24	22	0.1	16	0.9	40.50	15.00	141	6.5
	506	24	11	0.1	9	0.9	60.00	15.00	180	6.5
	810	24	7	0.1	6	0.9	60.00	15.00	180	6.5
工程师建议 The engineer recommends：30kg以上不支持堵转 Blocked(Stall) rotor is not supported above 30kg

新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current  (A)	转数Speed (RPM ±10%)	电流 Current  (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current  (A)
JGB37-555-1260	6.25	12	960	0.12	685	0.9	0.94	15.00	4	6.5
	10	12	600	0.12	428	0.9	1.50	15.00	4.8	6.5
	18.8	12	319	0.12	228	0.9	2.82	15.00	6	6.5
	30	12	200	0.12	142	0.9	4.50	15.00	18	6.5
	56	12	107	0.13	76	0.9	8.40	15.00	32	6.5
	90	12	66	0.13	50	0.9	13.50	15.00	52	6.5
	131	12	45	0.13	32	0.9	19.65	15.00	76	6.5
	169	12	35	0.13	25	0.9	25.35	15.00	87.5	6.5
	270	12	22	0.13	16	0.9	40.50	15.00	141	6.5
	506	12	11	0.13	9	0.9	60.00	15.00	180	6.5
	810	12	7	0.13	6	0.9	60.00	15.00	180	6.5
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current  (A)	转数Speed (RPM ±10%)	电流 Current  (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current  (A)
JGB37-555-2460	6.25	24	960	0.1	685	0.9	0.94	15.00	4	6.5
	10	24	600	0.1	428	0.9	1.50	15.00	4.8	6.5
	18.8	24	319	0.1	228	0.9	2.82	15.00	6	6.5
	30	24	200	0.1	142	0.9	4.50	15.00	18	6.5
	56	24	107	0.1	76	0.9	8.40	15.00	32	6.5
	90	24	66	0.1	50	0.9	13.50	15.00	52	6.5
	131	24	45	0.1	32	0.9	19.65	15.00	76	6.5
	169	24	35	0.1	25	0.9	25.35	15.00	87.5	6.5
	270	24	22	0.1	16	0.9	40.50	15.00	141	6.5
	506	24	11	0.1	9	0.9	60.00	15.00	180	6.5
	810	24	7	0.1	6	0.9	60.00	15.00	180	6.5
工程师建议 The engineer recommends：30kg以上不支持堵转 Blocked(Stall) rotor is not supported above 30kg

Household appliances: electric curtains, integrated stoves, coffee machines, smart toilets, sweeping robots, dishwashers, range hoods, smart door locks

Personal care: curling irons, massage equipment, electric hair clippers

Office equipment: paper shredders, printers, projectors, banknote counters, coin counters

Medical equipment: massage chairs, electric carts, medical pumps, electric beds, electric wheelchairs

Industrial equipment: water and electricity valves, air switches, pumps, automatic door switches, automatic lubrication equipment

Commercial equipment: vending machines, parking locks, ATM machines, smart lamps

Robots: manipulators, drones, service robots

Quantity: 100pcs/ctn Carton size: 38.5*27.5*24 cm Gross weight: 18.6 kg/ctn Net weight: 17.9 kg/ctn Unit weight: 179g
