新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGA25-2418-1245	4.4	12	990	0.035	740	0.08	0.03	0.2	0.2	0.05	17
JGA25-2418-1245	9.6	12	453	0.035	340	0.08	0.07	0.2	0.5	0.05
JGA25-2418-1245	21.3	12	204	0.035	150	0.08	0.16	0.3	1.0	0.05	19
JGA25-2418-1245	35	12	122	0.035	90	0.08	0.28	0.3	1.7	0.05	21
JGA25-2418-1245	45	12	93	0.035	70	0.08	0.37	0.3	2.3	0.05
JGA25-2418-1245	78	12	55	0.035	40	0.08	0.60	0.3	3.7	0.05	23
JGA25-2418-1245	103	12	42	0.035	30	0.08	0.80	0.3	5.0	0.05
JGA25-2418-1245	171	12	25	0.035	19	0.08	1.30	0.3	8.2	0.05	25
JGA25-2418-1245	226	12	19	0.035	14	0.08	1.80	0.3	11.0	0.05
JGA25-2418-1245	377	12	11	0.035	8	0.08	3.00	0.3	18.0	0.05	27
JGA25-2418-1245	500	12	8.5	0.035	6	0.08	4.00	0.3	24.0	0.05
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGA25-2418-2490	4.4	24	1932	0.05	1500	0.17	0.15	2.4	0.6	0.80	17
JGA25-2418-2490	9.6	24	886	0.05	682	0.17	0.30	2.1	1.4	0.80
JGA25-2418-2490	21.3	24	404	0.05	308	0.17	0.70	2.3	3.0	0.80	19
JGA25-2418-2490	35	24	242	0.05	185	0.17	1.17	2.3	5.0	0.80	21
JGA25-2418-2490	45	24	189	0.05	140	0.17	1.50	2.2	6.7	0.80
JGA25-2418-2490	78	24	109	0.05	85	0.17	2.80	2.5	11.0	0.80	23
JGA25-2418-2490	103	24	83	0.05	64	0.17	3.40	2.3	15.0	0.80
JGA25-2418-2490	171	24	50	0.05	38	0.17	5.60	2.2	24.0	0.80	25
JGA25-2418-2490	226	24	39	0.05	29	0.17	7.50	2.3	24.0	0.80
JGA25-2418-2490	377	24	23	0.05	17	0.17	12.50	2.2	24.0	0.80	27
JGA25-2418-2490	500	24	18	0.05	13	0.17	16.50	2.2	24.0	0.80
工程师建议 The engineer recommends：171速比以上不支持堵转 Blocked(Stall) rotor is not supported above 171 Ratio

新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGA25-2418-1245	4.4	12	990	0.035	740	0.08	0.03	0.2	0.2	0.05	17
JGA25-2418-1245	9.6	12	453	0.035	340	0.08	0.07	0.2	0.5	0.05
JGA25-2418-1245	21.3	12	204	0.035	150	0.08	0.16	0.3	1.0	0.05	19
JGA25-2418-1245	35	12	122	0.035	90	0.08	0.28	0.3	1.7	0.05	21
JGA25-2418-1245	45	12	93	0.035	70	0.08	0.37	0.3	2.3	0.05
JGA25-2418-1245	78	12	55	0.035	40	0.08	0.60	0.3	3.7	0.05	23
JGA25-2418-1245	103	12	42	0.035	30	0.08	0.80	0.3	5.0	0.05
JGA25-2418-1245	171	12	25	0.035	19	0.08	1.30	0.3	8.2	0.05	25
JGA25-2418-1245	226	12	19	0.035	14	0.08	1.80	0.3	11.0	0.05
JGA25-2418-1245	377	12	11	0.035	8	0.08	3.00	0.3	18.0	0.05	27
JGA25-2418-1245	500	12	8.5	0.035	6	0.08	4.00	0.3	24.0	0.05
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGA25-2418-2490	4.4	24	1932	0.05	1500	0.17	0.15	2.4	0.6	0.80	17
JGA25-2418-2490	9.6	24	886	0.05	682	0.17	0.30	2.1	1.4	0.80
JGA25-2418-2490	21.3	24	404	0.05	308	0.17	0.70	2.3	3.0	0.80	19
JGA25-2418-2490	35	24	242	0.05	185	0.17	1.17	2.3	5.0	0.80	21
JGA25-2418-2490	45	24	189	0.05	140	0.17	1.50	2.2	6.7	0.80
JGA25-2418-2490	78	24	109	0.05	85	0.17	2.80	2.5	11.0	0.80	23
JGA25-2418-2490	103	24	83	0.05	64	0.17	3.40	2.3	15.0	0.80
JGA25-2418-2490	171	24	50	0.05	38	0.17	5.60	2.2	24.0	0.80	25
JGA25-2418-2490	226	24	39	0.05	29	0.17	7.50	2.3	24.0	0.80
JGA25-2418-2490	377	24	23	0.05	17	0.17	12.50	2.2	24.0	0.80	27
JGA25-2418-2490	500	24	18	0.05	13	0.17	16.50	2.2	24.0	0.80
工程师建议 The engineer recommends：171速比以上不支持堵转 Blocked(Stall) rotor is not supported above 171 Ratio

Household appliances: electric curtains, integrated stoves, coffee machines, smart toilets, sweeping robots, dishwashers, range hoods, smart door locks

Personal care: curling irons, massage equipment, electric hair clippers

Office equipment: paper shredders, printers, projectors, banknote counters, coin counters

Medical equipment: massage chairs, electric carts, medical pumps, electric beds, electric wheelchairs

Industrial equipment: water and electricity valves, air switches, pumps, automatic door switches, automatic lubrication equipment

Commercial equipment: vending machines, parking locks, ATM machines, smart lamps

Robots: manipulators, drones, service robots

Quantity: 100pcs/ctn Carton size: 38.5*27.5*24 cm Gross weight: 7.7 kg/ctn Net weight: 7.0 kg/ctn Unit weight: 70g
