新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-31ZY-1280	6.25	12	1270	0.35	1050	1.0	1.3	12.0	3.0	6.5	19
JGB37-31ZY-1280	10	12	800	0.35	660	1.0	2.0	12.0	5.0	6.5
JGB37-31ZY-1280	18.8	12	420	0.35	350	1.0	3.8	12.0	9.0	6.5	22
JGB37-31ZY-1280	30	12	260	0.35	220	1.0	6.0	12.0	15.0	6.5
JGB37-31ZY-1280	56	12	140	0.35	110	1.0	11.2	12.0	27.0	6.5	24
JGB37-31ZY-1280	90	12	90	0.35	73	1.0	18.0	12.0	35.0	6.5
JGB37-31ZY-1280	131	12	60	0.35	50	1.0	26.0	12.0	Forbid over 35Kg.cm	Forbid Stall	26.5
JGB37-31ZY-1280	169	12	47	0.35	40	1.0	33.0	12.0
JGB37-31ZY-1280	270	12	30	0.35	24	1.0	35.0	12.0
JGB37-31ZY-1280	506	12	16	0.35	13	1.0	35.0	12.0			29
JGB37-31ZY-1280	810	12	10	0.35	8	1.0	35.0	12.0
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-31ZY-2480	6.25	24	1270	0.25	1050	1.0	1.3	12.0	3.0	4.4	19
JGB37-31ZY-2480	10	24	800	0.25	660	1.0	2.0	12.0	5.0	4.4
JGB37-31ZY-2480	18.8	24	420	0.25	350	1.0	3.8	12.0	9.0	4.4	22
JGB37-31ZY-2480	30	24	260	0.25	220	1.0	6.0	12.0	15.0	4.4
JGB37-31ZY-2480	56	24	140	0.25	110	1.0	11.2	12.0	27.0	4.4	24
JGB37-31ZY-2480	90	24	90	0.25	73	1.0	18.0	12.0	35.0	4.4
JGB37-31ZY-2480	131	24	60	0.25	50	1.0	26.0	12.0	Forbid over 35Kg.cm	Forbid Stall	26.5
JGB37-31ZY-2480	169	24	47	0.25	40	1.0	33.0	12.0
JGB37-31ZY-2480	270	24	30	0.25	24	1.0	35.0	12.0
JGB37-31ZY-2480	506	24	16	0.25	13	1.0	35.0	12.0			29
JGB37-31ZY-2480	810	24	10	0.25	8	1.0	35.0	12.0
工程师建议 The engineer recommends：35kg以上不支持堵转 Blocked(Stall) rotor is not supported above 35kg

新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-31ZY-1280	6.25	12	1270	0.35	1050	1.0	1.3	12.0	3.0	6.5	19
JGB37-31ZY-1280	10	12	800	0.35	660	1.0	2.0	12.0	5.0	6.5
JGB37-31ZY-1280	18.8	12	420	0.35	350	1.0	3.8	12.0	9.0	6.5	22
JGB37-31ZY-1280	30	12	260	0.35	220	1.0	6.0	12.0	15.0	6.5
JGB37-31ZY-1280	56	12	140	0.35	110	1.0	11.2	12.0	27.0	6.5	24
JGB37-31ZY-1280	90	12	90	0.35	73	1.0	18.0	12.0	35.0	6.5
JGB37-31ZY-1280	131	12	60	0.35	50	1.0	26.0	12.0	Forbid over 35Kg.cm	Forbid Stall	26.5
JGB37-31ZY-1280	169	12	47	0.35	40	1.0	33.0	12.0
JGB37-31ZY-1280	270	12	30	0.35	24	1.0	35.0	12.0
JGB37-31ZY-1280	506	12	16	0.35	13	1.0	35.0	12.0			29
JGB37-31ZY-1280	810	12	10	0.35	8	1.0	35.0	12.0
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-31ZY-2480	6.25	24	1270	0.25	1050	1.0	1.3	12.0	3.0	4.4	19
JGB37-31ZY-2480	10	24	800	0.25	660	1.0	2.0	12.0	5.0	4.4
JGB37-31ZY-2480	18.8	24	420	0.25	350	1.0	3.8	12.0	9.0	4.4	22
JGB37-31ZY-2480	30	24	260	0.25	220	1.0	6.0	12.0	15.0	4.4
JGB37-31ZY-2480	56	24	140	0.25	110	1.0	11.2	12.0	27.0	4.4	24
JGB37-31ZY-2480	90	24	90	0.25	73	1.0	18.0	12.0	35.0	4.4
JGB37-31ZY-2480	131	24	60	0.25	50	1.0	26.0	12.0	Forbid over 35Kg.cm	Forbid Stall	26.5
JGB37-31ZY-2480	169	24	47	0.25	40	1.0	33.0	12.0
JGB37-31ZY-2480	270	24	30	0.25	24	1.0	35.0	12.0
JGB37-31ZY-2480	506	24	16	0.25	13	1.0	35.0	12.0			29
JGB37-31ZY-2480	810	24	10	0.25	8	1.0	35.0	12.0
工程师建议 The engineer recommends：35kg以上不支持堵转 Blocked(Stall) rotor is not supported above 35kg

Household appliances: electric curtains, integrated stoves, coffee machines, smart toilets, sweeping robots, dishwashers, range hoods, smart door locks

Personal care: curling irons, massage equipment, electric hair clippers

Office equipment: paper shredders, printers, projectors, banknote counters, coin counters

Medical equipment: massage chairs, electric carts, medical pumps, electric beds, electric wheelchairs

Industrial equipment: water and electricity valves, air switches, pumps, automatic door switches, automatic lubrication equipment

Commercial equipment: vending machines, parking locks, ATM machines, smart lamps

Robots: manipulators, drones, service robots

Quantity: 100pcs/ctn Carton size: 38.5*27.5*24 cm Gross weight: 25.7 kg/ctn Net weight: 25.0 kg/ctn Unit weight: 250g
