新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-500-1264	6.25	12	1016	0.026	860	0.2	0.08	0.7	0.5	0.8	19
JGB37-500-1264	10	12	640	0.026	438	0.2	0.13	0.6	0.6	0.8
JGB37-500-1264	18.8	12	340	0.026	276	0.2	0.24	0.7	1.2	0.8	22
JGB37-500-1264	30	12	210	0.026	160	0.2	0.43	0.7	1.9	0.8
JGB37-500-1264	56	12	110	0.026	57	0.2	0.74	0.4	3.2	0.8	24
JGB37-500-1264	90	12	70	0.026	56	0.2	1.55	0.9	5.1	0.8
JGB37-500-1264	131	12	50	0.026	34	0.2	1.89	0.7	7.5	0.8	26.5
JGB37-500-1264	169	12	40	0.026	31	0.2	2.79	0.9	9.7	0.8
JGB37-500-1264	270	12	24	0.026	21	0.2	4.56	1.0	15.0	0.8
JGB37-500-1264	506	12	13	0.026	10	0.2	8.10	0.8	31.0	0.8	29
JGB37-500-1264	810	12	8	0.026	7	0.2	11.60	0.9	37.5	0.8
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-500-2464	6.25	24	1016	0.016	740	0.09	0.06	0.5	0.2	0.3	19
JGB37-500-2464	10	24	600	0.016	462	0.09	0.10	0.5	0.4	0.3
JGB37-500-2464	18.8	24	320	0.016	240	0.09	0.14	0.4	0.7	0.3	22
JGB37-500-2464	30	24	200	0.016	160	0.09	0.22	0.4	1.1	0.3
JGB37-500-2464	56	24	100	0.016	82	0.09	0.92	0.8	2.0	0.3	24
JGB37-500-2464	90	24	66	0.016	56	0.09	1.12	0.7	3.2	0.3
JGB37-500-2464	131	24	45	0.016	37	0.09	1.32	0.5	4.6	0.3	26.5
JGB37-500-2464	169	24	35	0.016	27	0.09	1.40	0.4	6.0	0.3
JGB37-500-2464	270	24	22	0.016	19	0.09	3.00	0.6	9.5	0.3
JGB37-500-2464	506	24	12	0.016	9	0.09	9.13	0.9	18.0	0.3	29
JGB37-500-2464	810	24	7	0.016	5.4	0.09	14.60	0.8	28.9	0.3
工程师建议 The engineer recommends：270速比以上不支持堵转 Blocked(Stall) rotor is not supported above 270 ratio

新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-500-1264	6.25	12	1016	0.026	860	0.2	0.08	0.7	0.5	0.8	19
JGB37-500-1264	10	12	640	0.026	438	0.2	0.13	0.6	0.6	0.8
JGB37-500-1264	18.8	12	340	0.026	276	0.2	0.24	0.7	1.2	0.8	22
JGB37-500-1264	30	12	210	0.026	160	0.2	0.43	0.7	1.9	0.8
JGB37-500-1264	56	12	110	0.026	57	0.2	0.74	0.4	3.2	0.8	24
JGB37-500-1264	90	12	70	0.026	56	0.2	1.55	0.9	5.1	0.8
JGB37-500-1264	131	12	50	0.026	34	0.2	1.89	0.7	7.5	0.8	26.5
JGB37-500-1264	169	12	40	0.026	31	0.2	2.79	0.9	9.7	0.8
JGB37-500-1264	270	12	24	0.026	21	0.2	4.56	1.0	15.0	0.8
JGB37-500-1264	506	12	13	0.026	10	0.2	8.10	0.8	31.0	0.8	29
JGB37-500-1264	810	12	8	0.026	7	0.2	11.60	0.9	37.5	0.8
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-500-2464	6.25	24	1016	0.016	740	0.09	0.06	0.5	0.2	0.3	19
JGB37-500-2464	10	24	600	0.016	462	0.09	0.10	0.5	0.4	0.3
JGB37-500-2464	18.8	24	320	0.016	240	0.09	0.14	0.4	0.7	0.3	22
JGB37-500-2464	30	24	200	0.016	160	0.09	0.22	0.4	1.1	0.3
JGB37-500-2464	56	24	100	0.016	82	0.09	0.92	0.8	2.0	0.3	24
JGB37-500-2464	90	24	66	0.016	56	0.09	1.12	0.7	3.2	0.3
JGB37-500-2464	131	24	45	0.016	37	0.09	1.32	0.5	4.6	0.3	26.5
JGB37-500-2464	169	24	35	0.016	27	0.09	1.40	0.4	6.0	0.3
JGB37-500-2464	270	24	22	0.016	19	0.09	3.00	0.6	9.5	0.3
JGB37-500-2464	506	24	12	0.016	9	0.09	9.13	0.9	18.0	0.3	29
JGB37-500-2464	810	24	7	0.016	5.4	0.09	14.60	0.8	28.9	0.3
工程师建议 The engineer recommends：270速比以上不支持堵转 Blocked(Stall) rotor is not supported above 270 ratio

Household appliances: electric curtains, integrated stoves, coffee machines, smart toilets, sweeping robots, dishwashers, range hoods, smart door locks

Personal care: curling irons, massage equipment, electric hair clippers

Office equipment: paper shredders, printers, projectors, banknote counters, coin counters

Medical equipment: massage chairs, electric carts, medical pumps, electric beds, electric wheelchairs

Industrial equipment: water and electricity valves, air switches, pumps, automatic door switches, automatic lubrication equipment

Commercial equipment: vending machines, parking locks, ATM machines, smart lamps

Robots: manipulators, drones, service robots

Quantity: 100pcs/ctn Carton size: 38.5*27.5*24 cm Gross weight: 15.3 kg/ctn Net weight: 14.6 kg/ctn Unit weight: 146g
