新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-555-1260	6.25	12	960	0.12	685	0.9	0.94	15.00	4	6.5
	10	12	600	0.12	428	0.9	1.50	15.00	4.8	6.5
	18.8	12	319	0.12	228	0.9	2.82	15.00	6	6.5
	30	12	200	0.12	142	0.9	4.50	15.00	18	6.5
	56	12	107	0.13	76	0.9	8.40	15.00	32	6.5
	90	12	66	0.13	50	0.9	13.50	15.00	52	6.5
	131	12	45	0.13	32	0.9	19.65	15.00	76	6.5
	169	12	35	0.13	25	0.9	25.35	15.00	87.5	6.5
	270	12	22	0.13	16	0.9	40.50	15.00	141	6.5
	506	12	11	0.13	9	0.9	60.00	15.00	180	6.5
	810	12	7	0.13	6	0.9	60.00	15.00	180	6.5
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current (A)	转数Speed (RPM ±10%)	电流 Current (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current (A)
JGB37-555-2460	6.25	24	960	0.1	685	0.9	0.94	15.00	4	6.5
	10	24	600	0.1	428	0.9	1.50	15.00	4.8	6.5
	18.8	24	319	0.1	228	0.9	2.82	15.00	6	6.5
	30	24	200	0.1	142	0.9	4.50	15.00	18	6.5
	56	24	107	0.1	76	0.9	8.40	15.00	32	6.5
	90	24	66	0.1	50	0.9	13.50	15.00	52	6.5
	131	24	45	0.1	32	0.9	19.65	15.00	76	6.5
	169	24	35	0.1	25	0.9	25.35	15.00	87.5	6.5
	270	24	22	0.1	16	0.9	40.50	15.00	141	6.5
	506	24	11	0.1	9	0.9	60.00	15.00	180	6.5
	810	24	7	0.1	6	0.9	60.00	15.00	180	6.5
工程师建议 The engineer recommends：30kg以上不支持堵转 Blocked(Stall) rotor is not supported above 30kg

新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)	重量Weight(G)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current  (A)	转数Speed (RPM ±10%)	电流 Current  (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current  (A)
JGB37-545-1260	6.25	12	960	0.3	740	1.00	1.5	15.0	3.0	3.8	19	260
JGB37-545-1260	10	12	600	0.3	460	1.00	2.5	15.0	5.0	3.8		260
JGB37-545-1260	18.8	12	319	0.3	250	1.00	5.0	15.0	9.4	2.8	22	265
JGB37-545-1260	30	12	200	0.3	150	1.00	7.5	15.0	15.0	3.8		265
JGB37-545-1260	56	12	107	0.3	82	1.00	14.0	15.0	28.0	3.8	24	270
JGB37-545-1260	70	12	85	0.3	65	1.00	15.0	15.0	35.0	3.8		270
JGB37-545-1260	90	12	66	0.3	50	1.00	17.0	15.0	35.0	3.8		270
JGB37-545-1260	131	12	45	0.3	35	1.00	24.0	15.0	Max Load 35kg	Forbid Stall	26.5	280
JGB37-545-1260	169	12	35	0.3	26	1.00	31.0	15.0				280
JGB37-545-1260	210	12	28	0.3	22	1.00	35.0	15.0				280
JGB37-545-1260	270	12	22	0.3	17	1.00	35.0	15.0				280
JGB37-545-1260	394	12	15	0.3	11	1.00	35.0	15.0			29	290
JGB37-545-1260	506	12	12	0.3	9	1.00	35.0	15.0
JGB37-545-1260	630	12	9.5	0.3	7	1.00	35.0	15.0
JGB37-545-1260	810	12	7	0.3	5	1.00	35.0	15.0
新永泰电机型号XYT Motor Model	减速比Reduction ratio	空载No-Load			额定负载Rated Load				堵转 Stall		减速箱长度Gearbox Length (MM)	重量Weight(G)
		额定电压Rated Voltage (V)	转数Speed (RPM ±10%)	电流 Current  (A)	转数Speed (RPM ±10%)	电流 Current  (A)	转矩Torque (Kg,cm)	功率 Power(W)	转矩Torque (Kg.cm)	电流 Current  (A)
JGB37-545-2460	6.25	24	960	0.2	740	1.00	1.5	24.0	3.5	2.8	19	260
JGB37-545-2460	10	24	600	0.2	460	1.00	2.5	24.0	5.5	2.8		260
JGB37-545-2460	18.8	24	319	0.2	250	1.00	5.0	24.0	10.0	2.8	22	265
JGB37-545-2460	30	24	200	0.2	150	1.00	8.0	24.0	17.0	2.8		265
JGB37-545-2460	56	24	107	0.2	82	1.00	14.0	24.0	31.0	2.8	24	270
JGB37-545-2460	70	24	85	0.2	65	1.00	16.0	24.0	35.0	2.8		270
JGB37-545-2460	90	24	66	0.2	50	1.00	18.0	24.0	35.0	2.8		270
JGB37-545-2460	131	24	45	0.2	35	1.00	25.0	24.0	Max Load 35kg	Forbid Stall	26.5	280
JGB37-545-2460	169	24	35	0.2	26	1.00	32.0	24.0				280
JGB37-545-2460	210	24	28	0.2	22	1.00	35.0	24.0				280
JGB37-545-2460	270	24	22	0.2	17	1.00	35.0	24.0				280
JGB37-545-2460	394	24	15	0.2	11	1.00	35.0	24.0			29	290
JGB37-545-2460	506	24	12	0.2	9	1.00	35.0	24.0
JGB37-545-2460	630	24	9.5	0.2	7	1.00	35.0	24.0
JGB37-545-2460	810	24	7	0.2	5	1.00	35.0	24.0

Household appliances: electric curtains, integrated stoves, coffee machines, smart toilets, sweeping robots, dishwashers, range hoods, smart door locks

Personal care: curling irons, massage equipment, electric hair clippers

Office equipment: paper shredders, printers, projectors, banknote counters, coin counters

Medical equipment: massage chairs, electric carts, medical pumps, electric beds, electric wheelchairs

Industrial equipment: water and electricity valves, air switches, pumps, automatic door switches, automatic lubrication equipment

Commercial equipment: vending machines, parking locks, ATM machines, smart lamps

Robots: manipulators, drones, service robots

Quantity: 100pcs/ctn Carton size: 38.5*27.5*24 cm Gross weight: 28.7 kg/ctn Net weight: 28 kg/ctn Unit weight: 280g
